Boikanyo Sheets and Plates is a renowned manufacturer and supplier based in Cape Town, South Africa, specializing in quality stainless steel. With a commitment to excellence we offer a wide range of stainless steel fabrics and plates, including durable stainless steel 446 sheet and plates. Known for excellent corrosion resistance and high thermal strength our products meet the needs of a variety of industries the solution of the. We pride ourselves on providing reliable, precision-made products that meet the highest industry standards at competitive prices
Stainless Steel 446 Sheet and Plates is a high chromium, ferritic alloy, known for excellent oxidation and corrosion resistance, especially in high temperature environments Its composition is usually 24-26% chromium, 0.20% carbon, 1.00% manganese , small amounts of silicon, sulfur and phosphorus. Mechanical properties include tensile strength of 480-620 MPa, yield strength of 250-450 MPa, and hardness of 160-220 HB. This alloy exhibits excellent thermal stability and scaling resistance, making it ideal for applications in furnace applications, heat exchangers, and other high-temperature environments.
| 446 Sheets & Plates Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 446 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 446 Sheets & Plates Size Range | Cold rolled ASME SA240 Grade 446 Stainless Steel Sheet 0.5-6.4 mm Hot rolled ASME SA240 Grade 446 Stainless Steel Sheet 3.0–10.0 mm |
| 446 SS Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| SS 446 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| SS 446 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Stainless Steel 446 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 446 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SA240 446 SS Strips EN 10088 SA -240-446 Strips |
| Finish of SS 446 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Stainless Steel 446 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| SS 446 | 0.2 max | 1.5 max | 0.75 max | 0.04 max | 0.030 max | 23 – 30 | – | 0.50 max | 0.10 – 0.25 | Balance |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.5 g/cm3 | 1510 °C (2750 °F) | Psi – 75,000 , MPa – 485 | Psi – 40,000 , MPa – 275 | 20 % |
| STANDARD | WERKSTOFF NR. | UNS | BS | EN | JIS |
| SS 446 | 1.4762 | S44600 | 446S21 | X12Cr13 | SUS 446 |
| Surface Finish | Definition | Application |
|---|---|---|
| 2B | Those finished, after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster. | Medical equipment, Food industry, Construction material, Kitchen utensils. |
| BA | Those processed with bright heat treatment after cold rolling. | Kitchen utensils, Electric equipment, Building construction. |
| NO.3 | Those finished by polishing with No.100 to No.120 abrasives specified in JIS R6001. | Kitchen utensils, Building construction. |
| NO.4 | Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, Building construction, Medical equipment. |
| HL | Those finished polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building Construction. |
| NO.1 | The surface finished by heat treatment and pickling or processes corresponding there to after hot rolling. | Chemical tank, pipe |
| Material | Size | Thickness |
| PLATES & SHEETS | 1000 mm x 2000 mm | 0.1mm To 100 mm Thickness |
| 1220 mm x 2440 mm (4′ x 8′) | ||
| 1250 mm x 2500 mm | ||
| 1500 mm x 3000 mm | ||
| 2000 mm x 4000 mm | ||
| 2000 mm x 2000 mm |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Stainless steel 446 sheets and plates have many advantages, making them ideal for high temperature applications. They provide exceptional resistance to oxidation, corrosion and scaling, even in extreme environments. The high chromium content increases the ability to withstand high temperatures and increases durability. These materials also provide excellent thermal conductivity and strength while maintaining structural integrity in extreme conditions. In addition, Stainless Steel 446 is resistant to chloride stress corrosion and cracking, making it suitable for use in industrial furnaces, heat exchangers, and other complex applications where reliability is critical.
Stainless steel 446 sheets and plates are widely used in hot, humid environments. It is commonly found in industrial furnaces, heat exchangers, and combustion chambers due to its excellent resistance to oxidation and scaling Other applications include power plants, fuel processing plants, and waste incinerators, where materials are exposed to high temperatures and strong chemicals. In addition, 446 stainless steel is used in combustion components, air filter systems and chimney inserts, providing superior strength, durability and corrosion and corrosion resistance pressure in complex situations.
