Boikanyo Sheets and Plates, located in Cape Town, South Africa, stands out as a top manufacturer and supplier of **Incoloy 800 / 800H / 800HT Channels**. These channels are celebrated for their remarkable high-temperature strength, resistance to corrosion, and impressive durability over time. Crafted from a nickel-iron-chromium alloy, they are precision-engineered to deliver reliable performance across various sectors, including chemical, petrochemical, power generation, and industrial applications. Boikanyo Sheets and Plates prides itself on utilizing advanced manufacturing techniques, rigorous quality control, and strict adherence to international standards, ensuring that every Incoloy 800 / 800H / 800HT channel consistently performs at a high level. The company caters to industries such as chemical processing, oil and gas, aerospace, and power generation, providing versatile and long-lasting channels that are perfect for critical structural and mechanical uses.
The **Incoloy 800 / 800H / 800HT Channels** are primarily made up of nickel, iron, and chromium, with small amounts of aluminum, titanium, and copper added in. The 800H and 800HT grades undergo heat treatment to boost their creep resistance and stability at high temperatures, while all grades boast impressive tensile strength ranging from 480–620 MPa, along with high yield strength and exceptional toughness. These channels are known for their outstanding resistance to oxidation, carburization, and stress corrosion cracking, even in high-temperature and corrosive settings, maintaining their structural integrity under thermal cycling and mechanical stress.
Specifications : ASTM B408 / ASME SB408
Angle Size Range : 20 x 20 mm to 100 x 100 mm
Angles Thickness : 3 to 12 mm (depending on size)
Channel Size Range : Base: 80 to 150 mm; Side: 40 to 75 mm
Channel Thickness : 5 to 6 mm (depending on size)
Length : 3MTR, 4MTR, 5MTR, 6MTR, or Custom Cut Sizes
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN | OR |
| Incoloy 800 | 1.4876 | N08800 | NCF 800 | NA 15 | ЭИ670 | Z8NC32-21 | X10NiCrAlTi32-20 | XH32 |
| Incoloy 800H | 1.4958 / 1.4876 | N08810 | NCF 800H | NA 15(H) | ЭИ670 | Z8NC33-21 | X5NiCrAlTi31-20 | XH32T |
| Incoloy 800HT | 1.4859 / 1.4876 | N08811 | NCF 800HT | NA 15(HT) | ЭИ670 | – | X8NiCrAlTi32-21 | XH32T |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy 800 | 0.10 max | 1.50 max | 1.00 max | 0.015max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800H | 0.05 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Incoloy 800HT | 0.06 – 0.10 | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Boikanyo Sheets and Plates based in Cape Town, South Africa, is a leading supplier and stockist of high-quality metal products, including Sheets, Plates, Coils, Foils, Angles, Channels, Circles, and Slitting Coils, all offered with exceptional service and tailored to meet our customers specific requirements. With a focus on delivering superior products, we cater to a wide range of industries, providing reliable solutions for diverse applications. Our extensive inventory includes Known for our unique finishing techniques and commitment to quality. We are dedicated to ensuring customer satisfaction through dependable service and top-notch products.
Incoloy 800, 800H, and 800HT channels offer several advantages, including exceptional resistance to oxidation, carburization, and thermal degradation at high temperatures. These alloys maintain strength and stability in extreme environments, making them ideal for applications in chemical processing, power plants, and heat exchangers. Incoloy 800H and 800HT variants provide enhanced creep strength and resistance to thermal fatigue, with 800HT offering superior stability at elevated temperatures. Additionally, these alloys exhibit excellent weldability, formability, and corrosion resistance, ensuring long-term reliability and durability in challenging industrial conditions.
Yes, we offer custom sizes for Incoloy 800 / 800H / 800HT Channel to meet specific project needs. Our team at Boikanyo Sheets and Plates is dedicated to providing tailored solutions for all your requirements. For more details, contact us at sales@aaronsheetsplates.com.
You’ll find **Incoloy 800 / 800H / 800HT Channels** widely utilized in chemical processing, petrochemical, power generation, and high-temperature industrial applications, thanks to their unique blend of strength, corrosion resistance, and long-lasting durability. They’re perfect for creating furnace components, structural supports, piping systems, heat exchangers, and parts for industrial machinery that face high temperatures and aggressive chemicals. Additionally, these channels are used in turbines, boilers, and high-performance equipment where reliability and longevity are crucial.
